Text and Ink Input and Display

Using Text

a view descended from

protoInputLine

with the

vApplication

flag set in

the

viewFlags

slot

The Caret Pop-up Menu

8

Normally, when the user taps the insertion caret, the system-provided Punctuation
pop-up Menu opens. However, you can override this with a pop-up menu of your
own creation.

When the user taps the insertion caret, the system starts searching for a slot named

_caretPopup

. The search begins in the view owning the caret, and follows both

the proto and parent inheritance paths. The default Punctuation pop-up is stored in
the root view.

The

_caretPopup

slot must hold a frame containing two slots. The first slot,

pop

, defines a list of pop-up items suitable for passing to

DoPopup

. The second

slot must contain a

pickActionScript

. If not, control passes to the punctuation

pop-up, which has its own version of the

pickActionScript

. This routine then

inserts a string, corresponding to the selected character at the caret, by using the
function

PostKeyString

.

Handling Input Events

8

You sometimes need to respond to input events that occur in text views. This
section describes how to test for a selection hit and respond to keystrokes and
insertion events.

Testing for a Selection Hit

8

After the user taps the screen, you can determine if the point "hits" a specific
character or word in a paragraph view.

The

view:PointToCharOffset

method returns the offset within the paragraph

that is closest to the point (x, y). This method is described in "PointToCharOffset"
(page 7-51) in Newton Programmer's Reference.

The

view:PointToWord

method returns a frame that indicates the position of

the word within the paragraph that is closest to the point (x, y). This method is
described in "PointToWord" (page 7-52) in Newton Programmer's Reference.

Both of these functions return

nil

if the view is not a paragraph

view. Also, the point you are testing must correspond to a visible
position within the paragraph view; you cannot hit-test on
off-screen portions of a view.
