eMate 300
Features a unique compact and rugged
design with an integrated handle
Is extraordinarily lightweight--only
4 pounds
Provides 20 to 30 hours of continuous
battery life (depending on usage)
Recharges in just one hour
Lets you control display backlighting for
optimal viewing, no matter where you are
Comes with a suite of productivity software,
including a word processor, a drawing
program, a spreadsheet, a graphing
calculator, a notepad, an address book,
and a calendar
Runs the easy-to-use Newton operating
system, which provides such functionality
as instant-on and auto-save
Lets you sketch, draw, and write directly on
the screen with the eMate Pen
Can take advantage of the hundreds of
available Newton applications
Connects easily to your Windows software­
based desktop PC or Macintosh computer
for file sharing (using the included cables
and connection software)
Makes it easy to access the Internet by
adding a modem and contracting with an
Internet service provider (web browser
Supports Ethernet networking through an
optional card
Supports direct connection to a wide variety
of printers
The Apple eMate 300 is a small
mobile computer that can make a
big difference in your family's life.
With its stylish yet rugged design
and affordable price tag, it lets you
learn, work, and create virtually
anywhere and anytime.
Weighing only 4 pounds, the
eMate 300 is easy to bring along
no matter where you go--around
the house or around the world. It
features an integrated handle that
makes carrying it a breeze, and its
compact size makes it easy to slip
into a backpack. Its unique design
is not only extremely portable, but
also incredibly rugged--well able to
withstand the rigors of use by the
entire family. And its outstanding
battery life (between 20 and 30
hours of continuous use) makes
the eMate 300 a virtually worry-free
tool for busy families on the go.
But style and durability are just
part of the eMate 300 story: The
most important thing to know about
this tiny, yet tough device is that
it's a highly capable computer. The
eMate 300 comes complete with
display, keyboard, and pen, as well
as built-in productivity software
(for writing, drawing and charting,
working with spreadsheets, and
more). So your child can use it to get
a head start on the day's homework
while carpooling back from soccer
practice. Or you can use it to catch
up on correspondence while sitting
in a doctor's waiting room. In fact,
virtually wherever you are, the
eMate 300 can be there, too.
It's the perfect companion--
not just for you and your family,
but also for your home computer.
Because whether you have a Windows
software­or a Mac OS­based system,
you can easily connect the eMate 300
to share files and information. So
when your family's demands on the
home computer get just a little too
demanding, the eMate 300 is ready
to ease the pressure. And with an
optional PC Card modem and the help
of an Internet service provider, you
can even use the eMate 300 to surf
the Web or send and receive e-mail.
The eMate 300: It's the ideal
way to give your family the flexible,
versatile computer access they need.
background image
Apple Computer, Inc.
1 Infinite Loop
Cupertino, CA 95014
(408) 996-1010
eMate 300
© 1998 Apple Computer, Inc. All rights reserved. Apple, the Apple logo, LaserWriter, LocalTalk, Mac, Macintosh, Newton, and StyleWriter are trademarks
of Apple Computer, Inc., registered in the U.S.A. and other countries. eMate is a trademark of Apple Computer, Inc. PostScript is a trademark of Adobe
Systems Incorporated. Mention of non-Apple products is for informational purposes only and constitutes neither an endorsement nor a recommendation.
Apple assumes no responsibility with regard to the selection, performance, or use of these products. All understandings, agreements, or warranties, if any,
take place between the vendors and the prospective users.
January 1998. Product specifications are subject to change without notice. Printed in the U.S.A.
Ordering Information
eMate 300
Order No. H0221LL/A
eMate 300 with built-in rechargeable nickel-
metal-hydride (NiMH) battery, AC power
adapter, serial cables for connection to
Mac OS­or Windows software­based
systems, CD containing desktop connectivity
software and web browser
eMate 300 2MB Memory Module
from NewerRAM
(1-800-678-3726 or
Provides an additional 2MB of internal Flash
RAM, for double the storage space and twice
the access speed
For more information on the eMate 300
and its accessories, visit our web site at
Product specifications are subject to change.
Check with your Apple reseller for the most
current information about product specifica-
tions and configurations.
Technical Specifications
Power and speed
25-MHz ARM 710a RISC processor
Infrared port for wireless data transfer within 3.3 feet
(1 meter)
--IrDA up to 115 kilobits per second
--Sharp ASK mode at 38.4 kilobits per second
Memory and storage
3MB of RAM (1MB of DRAM and 2MB of
Flash memory)
8MB of ROM
Internal slot for expanding memory
Interfaces and expansion
Serial port for connecting to printers, Mac OS­ or
Windows software­based computers, or LocalTalk
Newton InterConnect serial port for LocalTalk and
RS-232­compatible serial connections, modem,
power input/output, and sound input/output
One PC Card slot for Type I, Type II, or Type III PC
Cards (to add a modem, Ethernet networking, or
extra storage)
· Built-in TCP/IP capabilities enable Internet or
intranet access
480- by 320-pixel gray-scale LCD with backlighting
Displays up to 16 shades of gray
Built-in speaker and sound-output port
Microphone jack
Rechargeable nickel-metal-hydride battery provides
20 to 30 hours of continuous use without recharging
(depending on usage)
One-hour fast recharge using included power adapter
Computer connectivity requirements
Works with PC-compatible computers with 80386DX
or later processors (80486 recommended) running
Windows 3.1 or later
Works with Mac OS­based computers with 68030 or
later processors and Mac OS 7.1 or later
Printer support
Works with Apple Personal LaserWriter LS, Personal
LaserWriter 300, StyleWriter, and PostScript-
equipped LaserWriter printers
Supports the IrDA-compatible HP DeskJet 340 and
HP LaserJet 5MP and 6MP
Fax machine support
Faxes using optional fax modem (automatic cover-
page generation and post-formatting)
Power requirements
Line voltage: 100 to 220 volts AC
Frequency: 50 to 60 Hz
Operating environment
Operating temperature: 32
to 104
F (0
to 40
Transit temperature: ­18
to 140
F (­25
to 60
for up to 48 hours
Humidity: 5% to 95% noncondensing
Size and weight
Height: 12.0 in. (30.5 cm)
Width: 11.4 in. (29.0 cm)
Depth: 2.1 in. (5.3 cm)
Weight: 4.0 lb. (1.8 kg)
